Smart Retrofit for
HYDRANAUTICS HYDRAcap 60

; ;Hydranautics HYDRAcap 60;TAIKE-T-250-50-20

Membrane area;m2;46;50 Length with end caps (L);mm;1708,0 ± 3;1708,0 ± 3 Distance from bottom of lower end cap to central axis of lower inlet connection (A);mm;37,4;37,4 Distance between central axes of lower and top inlet connections (B);mm;1600 ± 3;1600 ± 3 Distance from central axis of top inlet connection to the top edge of outlet (C);mm;66,7;66,7 Distance from the central axis of module to the front edge surface of inlets (D);mm;160,3;160,3 Victaulic connection (d1);inch;2;2 Weight (wet);kg;70 ± 3;70 ± 3 Housing and caps material;-;PVC;PVC

; ;Hydranautics HYDRAcap 60;TAIKE-T-250-50-20

Quantity of bores in fiber;pcs.;1;1 Hollow fiber internal diameter (id);mm;0,8;0,8 Hollow fiber outside diameter (od);mm;1,4;1,3 Pores size;μm;0,02;0,02 Hollow fibers material;-;PESM;PESM

; ;Hydranautics HYDRAcap 60;TAIKE-T-250-50-20

Flux during filtration mode;m3/h;2,3-7,3;3,0-9,0 ;L/m2∙h;(50-160);(60-180) Flux during backwash mode;L/m2∙h;250;230-300

; ;Hydranautics HYDRAcap 60;TAIKE-T-250-50-20

TMP during filtration;bar;0,1-0,8;0,1-0,8 TMP during backwash;bar;<2,5;<2,5 Membrane burst pressure;bar;10;>10
