Smart Retrofit for
INGE DIZZER XL 60ST

; ;Inge Dizzer XL 60ST;TAIKE-I-250-60-T

Membrane area;m2;60;60 Length with end caps (L);mm;1878,0 ± 1,5;1878,0 ± 1,5 Length without end caps (L1);mm;1486,0 ± 1,5;1452,0 ± 1,5 Distance from bottom of lower end cap to central axis of lower inlet connection (A);mm;88;88 Distance between central axes T-Rack inlets (B);mm;1703;1703 Distance from the central axis of module to the front edge surface of inlets (C);mm;165;180 Distance from the central axis of module to the front edge surface of outlet (E);mm;133,5;133,5 Victaulic connection (d1) / (d2);inch;2 /6;2/6 Weight (wet);kg;63 ± 3;63 ± 3 Housing and caps material;-;PVC;PVC

; ;Inge Dizzer XL 60ST;TAIKE-I-250-60-T

Quantity of bores in fiber;pcs.;7;1 Hollow fiber internal diameter (id);mm;0,9;0,8 Hollow fiber outside diameter (od);mm;4;1,3 Pores size;μm;0,02;0,02 Hollow fibers material;-;PESM;PESM

; ;Inge Dizzer XL 60ST;TAIKE-I-250-60-T

Flux during filtration mode;m3/h;3,6-10,8;3,6-10,8 ;L/m2∙h;(60-180);(60-180) Flux during backwash mode;L/m2∙h;230-300;230-300

; ;Inge Dizzer XL 60ST;TAIKE-I-250-60-T

TMP during filtration;bar;0,1-1,5;0,1-1,2 TMP during backwash;bar;0,3-3,0;<2,8 Membrane burst pressure;bar;>10;>10
