Smart Retrofit for
INGE DIZZER XL 70WT

; ;Inge Dizzer XL 70WT;TAIKE-I-250-70-W

Membrane area;m2;70;70 Module length (L1);mm;1708,0 ± 1,5;1708,0 ± 1,5 Housing diameter;mm;250;250 Distance from the central axis of membrane module to the front edge outlet connection (A);mm;165;180 Distance between axes of T-Rack inlets;mm;1925;1925 Distance between central axis of outlet connection to the top edge of module (С);mm;133,5;133,5 Victaulic connection (d1);inch;2;2 Weight (wet);kg;56 ± 3;56 ± 3 Housing and caps material;-;PVC;PVC

; ;Inge Dizzer XL 70WT;TAIKE-I-250-70-W

Quantity of bores in fiber;pcs.;7;1 Hollow fiber internal diameter (id);mm;0,9;0,8 Hollow fiber outside diameter (od);mm;4;1,3 Pores size;μm;0,02;0,02 Hollow fibers material;-;PESM;PESM

; ;Inge Dizzer XL 70WT;TAIKE-I-250-70-W

Flux during filtration mode;m3/h;4,2-12,6;4,2-12,6 ;L/m2∙h;(60-180);(60-180) Flux during backwash mode;L/m2∙h;230-300;230-300

; ;Inge Dizzer XL 70WT;TAIKE-I-250-70-W

TMP during filtration;bar;0,1-1,5;0,1-1,2 TMP during backwash;bar;0,3-3,0;<2,8 Membrane burst pressure;bar;>10;>10
